Flyline Solar Battery less is specially designed and introduced by Murickens Group after the several years of experience. This system is very simple and compact system entirely free of maintenance and very useful for educational institution, hospital and shop .We develop these system to resolve headache of on-grid and off-grid system. These system economic and entirely pollution free main advantage of these system is there is no need of battery and permission of any authothrites and if require the system compensate the excess load with grid power.
In the case of conventional Grid Tied Inverters which are working without batteries, we can’t use even the available solar power during power failure and its installation requires prior permission and approval from KSEB. Flyline solar grid sharing system is an ideal for a category of power consumers like educational institutions, offices, shops etc, use a major percent of their total power consumption during day time. Our newly introduced Flyline battery less solar/mains compensation system is ideally suited for such consumers. This system has the advantages of ‘no battery’ over the conventional solar inverter system and ‘available solar power can be used’ over the grid tied inverter system. Moreover, as this system will not inject power to the grid, it can be installed without any permission from the authorities. This system is available with different power capacities starting from 3 KVA onwards and can be supplied as per customer’s power requirements.
FLYLINE BATTERYLESS INVERTER MORE IMAGES:-CLICK HERE
* No need of approval or permission from authorities. * No need of battery. * When solar energy is sufficient then total output load will operate on Solar through Flyline inverter. * When solar energy is weak then Flyline inverter is taking balance power from grid . * When solar energy is absent then the entire load is working on grid. * It will work on Solar as well as grid. * Compensating Type – First preference solar and second preference grid. * Eg.: If we install 5 KVA power conditioner unit (PCV) on-grid model with 3 KW solar panel for generating power, we draw 5 KVA load with a discharging difference of 2 KVA which will be taken from the grid. * We get full utilization of solar power. * Pure sine wave out put. * ISO: 9001 -2015 Certified solar power conditioner. * IGBT or MPPT with German PWM intelligent charging technology. * It will not support the backup power. * Work with solar power, the best way to save money using natural resource. * Pollution free type. * Protection from lightening, * Over Load Protection. * Independent Digital display inverter input and out put voltage, load, etc. * Audio and Visual Indicators. * Can connect to the existing wiring. * No husking sound. * It is a fully automatic built-in charging control.
Rating | 3 -6 KVA | 8 -10 KVA | 10-15 KVA | ||
DC Voltage | 72v | 192 v | 240 v | ||
Solar input Volt | 96 -160 v | 192-320 v | 240-400 v | ||
Grid Input | Single or 3 phase | ||||
Solar Charger | PWM based MPPT OR IGBT | ||||
Inverter type | IGBT based | ||||
Waveform | Pure Signwave | ||||
Output Voltage | 230 v (single phase) & 415 volt (3 phase) | ||||
Frequency | 50 Hz | ||||
Efficiency | 90% | ||||
Operating Mode | Solar /Grid | ||||
Changeovertime | 0 Seconds | ||||
Operating temp | 0-50 deg.celsius | ||||
Humidity | 95% non conditioning | ||||
Cooling | Air cooling / Oil cooling | ||||
LCD Display | Total output load,solar voltage, ac output voltage & solar utilisation % | ||||
Fault display | Fault display for DC low, and Checking status | ||||
Protections | Electronic protection & MCB | ||||
Alarm | Overload and DC low | ||||
